Product Details:
Payment & Shipping Terms:
|
| Type: | Granulating Production Line | Capacity: | 150kg/h |
|---|---|---|---|
| Material: | PP/PE, PE,PP,PET | Power: | 30Kw-132Kw |
| Blade Material: | 9CrSi Or SKD11 | ||
| High Light: | plastic auxiliary machinery,plastic processing machine |
||
PE/PP/LDPE waste film woven bags aggregate machine plastic pelletizing machine
Application:
BS series agglomerator can directly make waste plastic films and PET chips and PET/PP fiber and some other textile products into granules. It is suitable to agglomerate the waste products or films made of soft PVC, PET, HDPE, LDPE, PP and other thermo plastics.
The main functions of the plastic aggregator:
A1. Recycling of scraps and scraps of various soft plastic films, bags, wires, belts, sheets and tubes such as polyvinyl chloride, polypropylene, low-density polyethylene, high-density polyethylene, and linear low-density polyethylene. Invest in production.
A2. Recycling of degradable plastic film and horn crushing and granulation.
A3. The chemical fiber materials (polyester, acrylic, polypropylene, etc.) are pulverized, granulated, and put into recycling waste silk.
The main features of the plastic aggregator:
A: crushing, mixing, and coloring can be performed at one time.
D: Adjustable blade clearance, easy tool change
F: Low temperature granulation, basically does not destroy the molecular structure of the raw material, and does not damage the physical properties.
The pellets produced by this machine can be directly used in extruders and injection machines. For products with strict requirements, they can also be plasticized by extrusion granulator and used after granulation.
Details secification pictures of the plastic aggregator:
Technical datas of the plastic aggregator:
| BS-150 | BS-200 | BS-300 | BS-500 | BS-600 | BS-800 |
| Volume (L) | 150 | 200 | 300 | 500 | 600 |
| Effective volume (L) | 100 | 150 | 225 | 375 | 450 |
| Main shaft speed(r/min) | 1050 | 1000 | 950 | 750 | 750 |
| Output (kg/h) | 100 | 150 | 200 | 300 | 400 |
| Motor (kw) | 37 | 45 | 55 (75) | 90 | 110 |
| Weight (kg) | 1000 | 1200 | 1800 | 2500 | 2700 |
| Dimension (m) | 1.7*0.75*1.5 | 1.7*0.85*1.5 | 2*0.85*1.6 | 2.3*0.95*1.7 | 2.3*1.1*1.75 |
| Rotate blade quantity | 2 | 2 | 2 | 4 | 4 |
| Fixed blade quantity | 6 | 6 | 8 | 8 | 8 |
| Pot material | Stainless steel | ||||
| Blade material | 9CrSi | ||||
| Discharge method | Automatic / Manual | ||||
BEISU Machinery:
BEISU machinery and equipment recommendation: PVC/PE/PP pipe production line, PVC/PE wood plastic production line, PVC profile/profile production line, PVC/PP/PE/ABS sheet/sheet production line, PVC edge band production line and mill, High-speed mixer (group), crusher, sharpener, shredder, tractor, winder, cutting machine and other plastic auxiliary machinery.
Why choose BEISU Machinery:
A1:Plant construction, renovation plan, pipeline laying plan in the plant, construction plan of circulating cooling pool;
A2:Supply of raw materials, transformers, air compressors and other procurement plans;
A3:Provide relevant raw material specific formula, high quality raw material suppliers, raw material cost accounting ;
A4:Installation equipment, commissioning equipment, training staff, and provide technical support throughout the year;
A5:BEISU company has a plastics industry engineering alliance nationwide, in the case of distance, can provide relevant talents in your company year-round work, as a technology backing.
