18.5KW Extruder Power PVC Window Profile Extrusion Line , PVC Profile Production Line BS-180

18.5KW Extruder Power PVC Window Profile Extrusion Line , PVC Profile Production Line BS-180
18.5KW Extruder Power PVC Window Profile Extrusion Line , PVC Profile Production Line BS-180 18.5KW Extruder Power PVC Window Profile Extrusion Line , PVC Profile Production Line BS-180 18.5KW Extruder Power PVC Window Profile Extrusion Line , PVC Profile Production Line BS-180 18.5KW Extruder Power PVC Window Profile Extrusion Line , PVC Profile Production Line BS-180 18.5KW Extruder Power PVC Window Profile Extrusion Line , PVC Profile Production Line BS-180

Large Image :  18.5KW Extruder Power PVC Window Profile Extrusion Line , PVC Profile Production Line BS-180

Product Details:
Place of Origin: China
Brand Name: BEISU
Certification: CE
Model Number: BS-180
Payment & Shipping Terms:
Minimum Order Quantity: 1 Set
Price: Negotiable
Packaging Details: Plastic film packing and pallet fix the machine bottom
Delivery Time: 35 working days
Payment Terms: L/C, D/P, T/T
Supply Ability: 10 Set per month
Detailed Product Description
Material: PVC+addtives,Caco3 Products: PVC Ceiling Panel Profiles
Extruder Model: SJSZ51/105 Extruder Power: 18.5Kw
Vacuum Power: 4Kw Water Power: 4Kw
Haul Off Power: 3Kw Cutter Power: 2.2Kw
Inverter Brand: ABB Or Delta Temperature Control Brand: OMRON
High Light:

pvc profile manufacturing machine

,

pvc profile extrusion line

180 model Twin screw extruder PVC panle profile production line for window profile



Application:



PVC ceiling panel production line, also known as PVC siding production line, PVC hollow plastic material, is one of the common materials for decoration and decoration. It is widely used in kitchens, bathrooms, baths, shopping malls, etc. The color pattern on the surface of wallboard can be customized according to customer needs. It has the characteristics of colorful patterns.



PVC ceiling panel production line produced by BEISU can be modified to be used in the following production lines: PVC gusset production line, PVC siding production line, PVC foam board production line, PVC window sill production line, PVC ceiling production line, stone plastic line production line etc.





Layout:

PVC Raw material+additive→Mixing Unit→Auto Feeder→Conical Twin-screw Extruder→-Moulds→Vacuum Calibration Tank→Haul-off&Cutting Machine→Stacker



18.5KW Extruder Power PVC Window Profile Extrusion Line , PVC Profile Production Line BS-180 0





Features Specifications:





The PVC profile with added functional additives has anti-aging, anti-ultraviolet, anti-corrosion, high strength, low price, good heat preservation and heat insulation performance, and can partially replace aluminum profiles and steel.
The pollution is lower than the aluminum profile.





Details specification pictures of PVC ceiling panel production line:

18.5KW Extruder Power PVC Window Profile Extrusion Line , PVC Profile Production Line BS-180 1

18.5KW Extruder Power PVC Window Profile Extrusion Line , PVC Profile Production Line BS-180 2

18.5KW Extruder Power PVC Window Profile Extrusion Line , PVC Profile Production Line BS-180 3

18.5KW Extruder Power PVC Window Profile Extrusion Line , PVC Profile Production Line BS-180 4



Main technical parameter for Trunking &Ceiling conner&cable duct,Rain gutter:

Modle Product Range Extrusion Output(kg/hr) Line Speed(m/mim) KW Lenght(m)
PVC-55 150*80 150 0~10 80 15~20
PVC-45 150*80 100 0~10 60 15~20
PVC-45 150*80 60 0~10 40 12~20



Main technical parameter for Ceiling Panel,Windows,doors&Foam profiles:

Modle Product Range Extrusion Output(kg/hr) Line Speen(m/mim) KW Lenght(m)
PVC-80 240*100 360 0~10 120 24~28
PVC-65 240*100 240 0~10 100 22~25
PVC-55 150*80 150 0~10 80 20~24



1. Delivery method: delivery by the supplier factory, simple packaging of domestic customers' films, wooden packaging of foreign customers.

2. Mode of transportation: The supplier shall charge the consignment, and the expenses shall be borne by the acquirer.

3. Payment method: The buyer must prepay 30% of the total equipment to the supplier as a deposit; 70% of the total equipment will be paid before the equipment is processed; the equipment arrives at the demanding factory after commissioning.

4, quality assurance: equipment quality warranty period is one year.

5. Related after-sales service

a) Provide on-site installation instructions

b) Responsible for on-site commissioning of equipment (users provide room and board for commissioning personnel)

c) Responsible for pre-employment operation and maintenance training for the demand side personnel

d) Long-term guarantee of spare parts supply

e) Long-term technical advisory services

6. Delivery time: After the contract is signed and the deposit of the purchaser is received, the processing and production of the equipment is completed within 30 working days and the delivery conditions are met. (The factory only needs 3-7 working days for stocking).
