Type: | Two Shaft Shredder | Name: | Plastic Shredder Machine For Sale |
---|---|---|---|
Use: | Food Bags | Warranty: | 12 Months |
Voltage: | 380V/50Hz/3Phase | Plastic Type: | PP/PE |
Application: | Recycle Waste Plastic | ||
Highlight: | single shaft shredder machine,industrial plastic shredder |
Strong power double shaft shredder with PLC control for waste food bags
Product description:
The double-shaft shredder consists of the main structure of motor, hard-tooth surface reducer, rotary cutter shaft, moving knife, fixed knife, frame, base, box and working platform.
The fixed cutter is mounted on the frame, and the rotary cutter shaft is equipped with a detachable embedded movable knife. The number of movable cutters is determined according to different models and the size of the rotary cutter shaft, and the movable cutter is a four-corner knife that can be used, and is removed after being blunt. Angle, until the four sides are blunt and then sharpen the knife, because it is a claw type moving knife, rotary cutting, and the fixed knife and the movable knife are respectively imported SKD11 material, after heat treatment, the hardness reaches HRC60° or more, the service life is long, and the cutting ability is strong. High production capacity. The shredder adopts a two-axis linkage system, and the two rotating shafts work independently. After high-precision balance processing, the two shafts realize centripetal rotation. After the material is put into operation, the two-way cutting is realized, and the shredding is completed in more detail.
The electrical system is controlled by microcomputer PLC programming and is fully automated. After the commissioning is completed, the operator only needs to press F3 to start the machine automatically, and the F4 machine will stop automatically. Save labor costs while ensuring a safe operating environment.
Details specification pictures:
Main technical parameter:
Model | VD-3060 | VD-3080 | VD-30100 | VD-30120 | VD-35120 | VD-4380 | VD-43120 | VD-43150 |
Capacity(kg/hr) | 300 | 500 | 800 | 1000 | 1200 | 500-800 | 1500-2000 | 2500 |
Shredding chamber(mm) | 600x575 | 800x600 | 1000x600 | 1200x600 | 1200x650 | 1200x770 | 1200x770 | 1500x770 |
blades diameter(mm) | 300 | 300 | 300 | 300 | 350 | 430 | 430 | 430 |
Shafts number | 2 | 2 | 2 | 2 | 2 | 2 | 2 | 2 |
Speed (RPM) | 18 | 18 | 18 | 18 | 18 | 19 | 19 | 19 |
Motor power (KW) | 7.5+7.5 | 15+15 | 18.5+18.5 | 22+22 | 22+22 | 15+15 | 30+30 | 45+45 |
Blade material | SKD-11 | SKD-11 | SKD-11 | SKD-11 | SKD-11 | SKD-11 | SKD-11 | SKD-11 |
How to install the double-shaft crusher in various departments is very concerned by all users. Many production lines, such as crushing production line, crushing stone production line, stone production line, sand production line, sand and gravel production line, in the crushing production line, solve the good double The problem of the shaft crusher almost solved the problem of the entire production line. The double-shaft crusher is the most critical part of the production line and has become the core equipment.
So how do we install the double-shaft crusher? After purchasing the double-shaft crusher, the first step is to install it. There must be professionals at the time of installation to prevent inefficiency in future work. factor. We should first check if the power switch is normal, so that we can start the twin-shaft crusher equipment. During the installation process, we have to check the center line of the double-shaft crusher to see if it is accurate. Secondly, we need to wrap the center line on the foundation. Mark the axial line of the neck bearing, then check the position of the bolt hole. After checking, you can install the motor and reducer. The installation of the double-shaft crusher is not complicated, but it requires certain technology. We can't just use it. To install, you may feel right, but some small installations will cause large deviations, which will cause inconvenience to the work, so the company reminds the manufacturers to break the double shaft when installing the crushing production line. The machine is installed correctly.
