Solid Structure Single Shaft Shredder Machine 320mm - 630mm Rotated Diameter

Solid Structure Single Shaft Shredder Machine 320mm - 630mm Rotated Diameter
Solid Structure Single Shaft Shredder Machine 320mm - 630mm Rotated Diameter Solid Structure Single Shaft Shredder Machine 320mm - 630mm Rotated Diameter Solid Structure Single Shaft Shredder Machine 320mm - 630mm Rotated Diameter Solid Structure Single Shaft Shredder Machine 320mm - 630mm Rotated Diameter

Large Image :  Solid Structure Single Shaft Shredder Machine 320mm - 630mm Rotated Diameter

Product Details:
Place of Origin: China
Brand Name: BEISU
Certification: CE
Model Number: BS-800
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: Negotiable
Packaging Details: Plastic film with wooden tray
Delivery Time: 30 working days
Payment Terms: D/P, L/C, T/T
Supply Ability: 80 sets per year
Detailed Product Description
Shaft Quantity: 1 Fixed Knife: 1 Pcs
Motor Power: 45kw PLC Brand: SIEMENS
Weight: 3500kg
High Light:

single shaft shredder machine

,

industrial plastic shredder

BS-800 model single shaft shredder machine for PE/PEX pipe hard material



Application:

Single shaft plastic shredder is mainly used in all kinds of hollow or solid plastic material. The shredder machine is suitable to PE, PP, PET, ABS, PVC and plastic container and barrel, plastic film, plastic pipe, fiber and paper which the normal crusher can not handle.The materials are pushed into the shredding chamber by hydraulic. Independent drive system and solid structure make the running stably.

Features:
A1. Low dust, low noise and easy to operate.
A2. This machine is suitable to treat the big size of plastic product, such as headpiece material, thick-walled large diameter plastic pipe, film roller, paper, fibre and others.
A3. The blade base and blade on the rotary roller can be disassembly. It is easy to clean and maintenance.
A4. The rotary blade use V shape installation so that the blade can cut material evenly, it can decrease the noise and decrease energy consumption.
A5. Each rotary blade with 4 cutting knife edge, when the rotary blade is wear, it can be rotated to 90 degree, then the blade can continue to use.
A6. Each fixed blade with 2 cutting knife dege, when the fixed blade is wear, it can be rotated to 180 degree, then the blade can continue to use.
A7. The main axis is drive by gearbox, its running very stably, low noise and strong power.
A8. The material push feeding system is hydraulic ways, its running is very stably.
A9. PLC program control system, automatically rotating, shut down, safe and reliable running of the machine. The blade can rotate in opposite direction.



Details specification pictures:

Solid Structure Single Shaft Shredder Machine 320mm - 630mm Rotated Diameter 0Solid Structure Single Shaft Shredder Machine 320mm - 630mm Rotated Diameter 1Solid Structure Single Shaft Shredder Machine 320mm - 630mm Rotated Diameter 2

Solid Structure Single Shaft Shredder Machine 320mm - 630mm Rotated Diameter 3



Main technical parameter:

Model number BS-600 BS-800 BS-1000 BS-1200
Quantity of rotated blade 32pcs 38pcs 50pcs 95pcs
Quantity of seated blade 2 sets 2 sets 2 sets 2 sets
Material of blades SKD-11 SKD-11 SKD-11 SKD-11
Rotated diameter 320mm 400mm 520mm 630mm
Input size 520*520mm 900*720mm 1000*920mm 1500*1300mm
Main motor power 22KW 37KW 45KW 90KW
Screen diameter >80mm >80mm >80mm >80mm
Capacity 400-600kg/h 500-800kg/h 700-1000kg/h 1000-1500kg/h
Controller PLC PLC PLC PLC
Rotating speed 80-100rpm 80-100rpm 80-100rpm 80-100rpm



BEISU Machinery:

BEISU machinery and equipment recommendation: PVC/PE/PP pipe production line, PVC/PE wood plastic production line, PVC profile/profile production line, PVC/PP/PE/ABS sheet/sheet production line, PVC edge band production line and mill, High-speed mixer (group), crusher, sharpener, shredder, tractor, winder, cutting machine and other plastic auxiliary machinery.



Why choose BEISU Machinery:
A1:Plant construction, renovation plan, pipeline laying plan in the plant, construction plan of circulating cooling pool;

A2:Supply of raw materials, transformers, air compressors and other procurement plans;

A3:Provide relevant raw material specific formula, high quality raw material suppliers, raw material cost accounting ;

A4:Installation equipment, commissioning equipment, training staff, and provide technical support throughout the year;

A5:BEISU company has a plastics industry engineering alliance nationwide, in the case of distance, can provide relevant talents in your company year-round work, as a technology backing.
