800Kg/h Waste recycle plastic pulverizing powder milling manufacturer price

Certification
China Zhangjiagang Beisu Machinery Co., Ltd. certification
China Zhangjiagang Beisu Machinery Co., Ltd. certification
The quality of the machine of Beisu Machinery is very stable, the output is high, the details are very user friendly, and they provide a quick response when we need service.

—— Ahmed Zeitoun

The quality of the high speed mixer produced by Beisu Machinery is outstanding. We have ordered 3 sets of equipment and they are all in use. Maria provides our professional and prompt after sales service.

—— Adrew

I'm Online Chat Now

800Kg/h Waste recycle plastic pulverizing powder milling manufacturer price

800Kg/h Waste recycle plastic pulverizing powder milling manufacturer price
800Kg/h Waste recycle plastic pulverizing powder milling manufacturer price 800Kg/h Waste recycle plastic pulverizing powder milling manufacturer price 800Kg/h Waste recycle plastic pulverizing powder milling manufacturer price 800Kg/h Waste recycle plastic pulverizing powder milling manufacturer price 800Kg/h Waste recycle plastic pulverizing powder milling manufacturer price

Large Image :  800Kg/h Waste recycle plastic pulverizing powder milling manufacturer price

Product Details:
Place of Origin: CHINA
Brand Name: BEISU
Certification: CE
Model Number: MF-800
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: $19,000.00
Packaging Details: Wooden case package or film package
Delivery Time: 35 working days
Payment Terms: L/C, T/T
Supply Ability: 100 sets per year
Detailed Product Description
Grinding Material: PE/PET/HDPE/LDPE/LLDPE/MDPE/ABS/PC/PMMA/SEBS/SBS Capacity: 150~1000Kg/h
Motor Power: 75Kw Off Fan Power: 1.5Kw
Blow Motor Power: 7.5Kw Vibrator Motor Power: 1.5Kw
Blade Material: SKD-11 Or D2 Mesh: 10~80
Voltage: 220V/380V/415V/440V Bearing Brand: NSK Or SKF

The main application fields of plastic mills are as follows:
800Kg/h Waste recycle plastic pulverizing powder milling manufacturer price 0

A1. Chemical field:

-Plastic grinding machine is used in the chemical industry to process various plastic materials and realize grinding processing.

A2. Waste recycling:

-The plastic grinding machine can grind the plastic waste into small particles, and then add new materials to mix into new plastic products, so as to realize the reuse of waste and effectively reduce resource waste and environmental pollution.

-For example, when recycling plastic waste, a plastic grinder can grind the waste to a suitable particle size for subsequent disposal and reuse.

A3. Manufacturing of plastic pipe sections:

-In the production process of plastic pipes and profiles, the plastic grinder can grind large pieces of plastic raw materials into small particles, which facilitates subsequent processing and production and improves production efficiency.

A4. Plastic Modification:

-Plastic grinding machine is applicable to plastic modification field. It can grind all kinds of soft and hard leather into fiber or powder under normal temperature, especially suitable for artificial leather, PVC, PE and other materials with different molecular structures.

A5. Pigment Manufacture:

-Particle fineness has a great influence on the quality and processing performance of pigment. The plastic grinding machine can realize the processing of pigment powder and improve the color stability and uniformity of pigment.



Working principle of plastic grinding machine:

A1. Operating principle:

-The plastic disc grinder is mainly used to cut the materials (plastic scraps) into powder through strong collision between the high-speed rotating disc and the fixed cutter.

-The materials enter the machine body from the feeding hopper through the vibrating feeder. The grinding plate driven by the main shaft rotates at high speed and collides with the fixed cutter to complete the grinding process.

-The ground powder is sent to the cyclone by the discharge fan for separation, and then sent out of the bag by the shutdown fan, while the air is discharged through the dust collection device.

A2. Main components of plastic grinding machine:

-Feeding system: responsible for introducing plastic scraps into the grinder.

-Grinding system: the core is high-speed rotating grinding plate and fixed cutter plate, which is responsible for grinding materials into powder.

-Discharging system: send the grinded powder for subsequent collection or treatment.

-Drive system: drive key parts such as grinding disc to rotate at high speed.
-Electrical control system: monitor and control the operation of the whole equipment.


Technical datas for Plastic pulverizer machine:

Mode MF-500 MF-600 MF-800
Pulverizing chamber diameter φ483 +1 φ583 +1 φ783 ±1
Main motor power (kw) 37/45 55/75/90 110/132
Rotary blade (pc) 24 28 36
Static blade (pc) 12 14 19
Type of cooling water, forced air
Suction fan power (kW) 4/5.5 7.5/11 11/15
Off fan power (kW) 1.1/1.5/2.2 1.1/1.5/2.2 1.1/1.5/2.2
Vibration screen(mm) ZDS-800/1000 ZDS-1200/1500 ZDS-1500
Output (kg) 200-550 450-850 750-1350
Weight (kg 1500 1800 2000
Size(mm) 1700*790 1800*790 1900*790



800Kg/h Waste recycle plastic pulverizing powder milling manufacturer price 1

800Kg/h Waste recycle plastic pulverizing powder milling manufacturer price 2

800Kg/h Waste recycle plastic pulverizing powder milling manufacturer price 3

800Kg/h Waste recycle plastic pulverizing powder milling manufacturer price 4

800Kg/h Waste recycle plastic pulverizing powder milling manufacturer price 5



800Kg/h Waste recycle plastic pulverizing powder milling manufacturer price 6

800Kg/h Waste recycle plastic pulverizing powder milling manufacturer price 7

800Kg/h Waste recycle plastic pulverizing powder milling manufacturer price 8

800Kg/h Waste recycle plastic pulverizing powder milling manufacturer price 9

• For the loose cargo we will packing by wooden box.
• For the full container loading we are packing the machine by film and some on pallet accordingly.
• We can ship the goods by air or by sea.
• We will send pictures of cargo loading to our client to check and keep recording.
• We can send cargo to client's warehouse to loading.

800Kg/h Waste recycle plastic pulverizing powder milling manufacturer price 10

• Pre-sale: we give our client the detailed technician offer, sign the sales contract etc.
• In-sales: we supply the details layout, installation instruction, and technician support for the clients.
• After sales: we arrange engineer to install the machine and train the workers for our client.
• We have 24 hours service line to solve the after sales problem.
• We have free spare parts with the machine.
• We supply long term spare parts for every customer.
• We always update the new technology to every customer.
