Product Details:
Payment & Shipping Terms:
|
| Condition: | New | Material: | Stainless Steel |
|---|---|---|---|
| Output (kg/h): | 10 - 20kg/h | Capacity (kg): | 2.5 |
| Video Outgoing-inspection: | Provided | Machinery Test Report: | Provided |
| Marketing Type: | New Product 2020 | Warranty Of Core Components: | 1 Year |
| Core Components: | Pump, Pump, Pump, Pump, Pump, Pump, Pump | Application: | Plastic Mixer |
| Automatic Grade: | Automatic | Voltage: | Customzied |
| Dimension(L*W*H): | Customized | Warranty: | 1 Year |
| After-sales Service Provided: | Video Technical Support, Video Technical Support, Video Technical Support, Video Technical Support, Video Technical Support | Weight (KG): | 200 KG |
| Power (kW): | 3 | Applicable Industries: | Food & Beverage Factory, Food & Beverage Factory |
| After Warranty Service: | Field Maintenance And Repair Service, Field Maintenance And Repair Service, Field Maintenance And Repair Service, Field Maintenance And Repair Service | Local Service Location: | Algeria, Algeria, Algeria |
| Showroom Location: | None, None, None, None, None, None, None, None, None, None, None, None, None, None, None, None | Raw Material: | PVC/PE/PP Powder, Granules Or Liquid |
| Mixing Speed: | 1400 RPM | Material Of Mixing Blade: | S.S304 |
| Method Of Mixing Blade: | Double Propellers | Hot Mixing Motor Power: | 3Kw |
| Mixing Bearing Brand: | NSK, SKF Or WANFANDIAN | Cold Mixing Drive Method: | Belt Reducer |
| Temperature Brand: | OMRON,JAPAN | Contactor Brand: | SCHNEIDER Or SIEMENS |
| Port: | SHANGHAI Or NINGBO PORT | ||
| Highlight: | 2.5KG Pvc Mixer Machine,ISO pvc mixer machine,pvc mixer machine 20kg/h |
||
High-speed Mixer designed to generate heat due to friction. The high-speed Mixers are used to mix granules with pigment paste or pigment powder or different colored granules for uniform blending. The high-speed mixer achieves heat while working is important to blend the pigment paste and polymer powder uniformly.
High-Speed Mixer:
A1. Used for the processes of compounding, mixing, drying and dying as one of the most ideal equipment for the manufactures of profiles and tubes.
A2. The cold mixer adopts horizontal structure with the characteristics of large cooling area, fast speed, more homogenized.
A3. The mixer lid is double sealed and opened in the pneumatic way.
A4 The electric control system adopts RKC, Siemens, ABB, Omron and other famous instruments and control components to realize automatic control.
A5. Equipped with pulse dust catching device. (on customer's option)
A6. Both the blades and the belt wheel have been specially treated through the balancing machine of static and dynamic.
| Model | Capacity(L) | Motor power(kw) | Mainshaft speed rpm(r/min) | Heating method | Gischarge method |
| SHR-5A | 5 | 2.2 | 600-3000 | Electrical steam | Hand work |
| SHR-10A | 10 | 3 | 600-3000 | ||
| SHR-50A | 50 | 7/11 | 750/1500 | Pneumatics | |
| SHR-100A | 100 | 14/22 | 650/1300 | ||
| SHR-200A | 200 | 30/42 | 575/1050 | ||
| SHR-300A | 300 | 40/55 | 625/1100 | ||
| SHR-500A | 500 | 47/67 | 500/1000 | ||
| SHR-800A | 800 | 60/90 | 370/740 |
| Model/Specs | SRL-Z100/200 | SRL-Z200/500 | SRL-Z300/600 | SRL-Z500/1000 | SRL-Z800/1600 | |
| Total Cubage (L) | 100/200 | 200/500 | 300/600 | 500/1000 | 800/1600 | |
| Effective Cubage (L) | 65/130 | 150/620 | 225/380 | 375/650 | 600/1050 | |
| Mixed Speed(r/min) | 650/1300/80 | 475/950/80 | 475/950/80 | 430/860/60 | 370/740/50 | |
| Heating&Cooling Manner | Electric Heating, Self-friction/water-cooling | |||||
| Mixed Time(min) | 8-12 | 8-12 | 8-12 | 8-12 | 8-12 | |
| Motor Powder(KW) | 14/22/7.5 | 30/42/11 | 40/55/11/ | 47/67/15 | 60/90/22 | |
