| Name: | Plastic Shredder/shredding Machine | Suitable Material: | PVC/WPC/PP/PE/PPR/PC/ABS/PMMA/PS |
|---|---|---|---|
| Blade Material: | D2 | Motor Power: | 75 Or 90Kw |
| Output Capacity: | 0.5~20ton/Hour. | Shaft Dia (mm): | 220mm,280mm,400mm |
| Running: | Automatic Operation | System: | Frequency-Controlled Hydraulic System |
| Highlight: | Pipes Plastic Shredder Machine,Waste Recycling Plastic Shredder Machine,Single Shaft Plastic Shredder Machine |
||
Plastic shredder machine was main used to shred different kinds of plastic materials, especially very large waste plastic.
single shaft shredder machine can shredding plastic lumps, barrels, pipes , wood, wood pallet, big block material, plastic
container, plastic chair , plastic pallet, woven bags ,jumbo bags, cable Etc.
Features of Plastic recycle single shaft shredder:
A1. The single shaft shredder can efficiently recyclea large number of difficult processedmaterials,
such as large and hard solid materials (extruder block, large diameter tubes), roll films, paper, and fibers.
A2. The bladeshaft is removable for easy cleaning and maintenance.
A3. The rotary knife is set with a V-shape, which can balance grinding and reduce noise and power consumption.
A4. Each rotating knife has 4 cutting heads, which can be rotated for 90 ° after wear and continue to be used.
A5. Each fixed knife has two blades, which can be rotated 180 ° after wear and can be reused.
A6. The bladeshaft is rotated using a gear reducer, with low noise, balanced work, and high torque.
A7. Hydraulic transmission material with independent power system.
Technical datas for Waste plastic singles shredder:
| Model | BS600 | BS700 | BS800 | BS1000 | BS1200 | BS1500 |
| Motor power/kw | 22 | 37 | 45 | 55 | 75 | 90/110 |
| Rotating blade quantity/pcs | 26+4 | 30+4 | 36+6 | 48+6 | 58 | 98 |
| Fixed blade quantity/pcs | 4 | 4 | 4 | 4 | 4 | 6 |
| Blade material | SKD-11/D2/DC53 | SKD-11/D2/DC53 | SKD-11/D2/DC53 | SKD-11/D2/DC53 | SKD-11/D2/DC53 | SKD-11/D2/DC53 |
| Shaft rotating speed/rpm | 75 | 75 | 75 | 75 | 80 | 80 |
| Shaft rotating diameter/mm | 260 | 280 | 400 | 400 | 400 | 550 |
| Shredding room dimension/mm | 600x600 | 700x600 | 800x800 | 1000x1000 | 1200x1200 | 1500x1500 |
| Hydraulic power/kw | 2.2 | 2.2 | 3 | 4 | 5.5 | 7.5 |
| Cylinder movement length/mm | 600 | 600 | 800 | 1000 | 1200 | 1500 |
| Overall dimension/mm | 1800x1600x1850 | 1830x1750x1850 | 2200x1780x2100 | 2500x1850x2300 | 3500x2000x2400 | 4800x2350x2400 |
| Machine weight/kg | 2200 | 3000 | 3700 | 4500 | 7000 | 9200 |
Functions:
A1: Material Size Reduction: The primary function is to cut and shred materials into smaller, more manageable pieces, making them easier to handle, transport, and process.
A2: Efficient Waste Management: By reducing the volume of waste materials, it helps in efficient waste management, making disposal more cost-effective and environmentally friendly.
A3: Preparation for Recycling: Shredded materials are easier to sort, clean, and process in recycling facilities, enhancing the overall efficiency of recycling operations.
A4: Resource Recovery: By breaking down materials into smaller pieces, valuable resources can be recovered and reused, supporting sustainable practices.
A5: Operational Efficiency: Its robust design and powerful motor ensure consistent performance, minimizing downtime and maintenance needs, and increasing overall operational efficiency.
1. Before shipment testing at factory, vedio record.
2. Vedio instruction for operation.
3. User manual and installation instruction, layout and drawings.
4. Lable&marks for disassemble parts, wiring&cables.
1.Reliable
Most popular design with years' verification.
Mature supply chain for raw materials with strict quality assurance.
International famous brands of key parts i.e. ABB invertor, Siemens electronics, Siemens motor, Mettler Toledo scale etc.
2. Economy
BEISU Stable technology commercialized in China.
High efficiency mixing performance.
Cost effective solutions.
Real time communication SNS group chat(WeChat preferred, Skype/WhatsApp) which includes buyer side and BEISU service team is created for technical assistance in the quickest manner. Scheduled video calls are also available. Just as the company vision 'Customer Oriented' says,BEISU always stands at customer's point to offer the optimum solution and help customer to maximize profit. BEISU has its own customer management system and spare parts management system which ensure quickest responds and enough regular easy-wearing parts whenever customer requests.
