1000kg / H High Speed Plastic Pulverizer Machine For PVC / PP / ABS / EVA Material

1000kg / H High Speed Plastic Pulverizer Machine For PVC / PP / ABS / EVA Material
1000kg / H High Speed Plastic Pulverizer Machine For PVC / PP / ABS / EVA Material 1000kg / H High Speed Plastic Pulverizer Machine For PVC / PP / ABS / EVA Material 1000kg / H High Speed Plastic Pulverizer Machine For PVC / PP / ABS / EVA Material

Large Image :  1000kg / H High Speed Plastic Pulverizer Machine For PVC / PP / ABS / EVA Material

Product Details:
Place of Origin: China
Brand Name: BEISU
Certification: CE
Model Number: BS-1000
Payment & Shipping Terms:
Minimum Order Quantity: 1 Set
Price: Negotiable
Packaging Details: Plastic film packing and pallet fixed on the machine bottom
Delivery Time: 20 working days
Payment Terms: L/C, D/P, T/T, Western Union
Supply Ability: 10 Sets per month
Detailed Product Description
Material: PVC/PE/PP/PET/EVA/ABS/Fiber Miller Model: BS-PVC-1000
Motor Power: 90Kw Fan Power: 7.5Kw
Vibrator Power: 1.1Kw Capacity: 1000Kg/h
High Light:

plastic grinding pulverizer machine

,

plastic grinding machine



1000kg/h High speed Plastic pulverizer miller for PVC/PP/ABS/EVA material



Plastic pulverizer machine introduction:

The plastic mill http://www.beisu-extrusion.comcan be divided into two types: grinding disc type and cutter disc type. The grinding disc grinding machine mainly cuts and grinds the material by the gap between the two grinding discs. The cutter disc type grinder is driven by the material and the cutter head. Grinding, plastic mill is named after years of practical performance and operation. Based on the absorption and introduction of foreign advanced equipment, Jianuo Machinery has successfully designed and developed to meet the needs of customers. Ideal equipment for PVC, high density PE, PS, SBS, foamed PE, EVA, soft PVC and other thermoplastic materials, plant fiber and leather. It is also a processing equipment for recycling and recycling of plastic products. It is a good helper for plastic products enterprises to solve the problem of waste product backlog and reduce costs. It has high output, low energy consumption, can be adjusted freely, easy to maintain, environmentally friendly and pollution-free. Compared with similar products, it has upgraded to a new level.



Plastic pulverizer machine function:

A1:The main shaft transmission parts are made of Japan NSK bearing. The exhaust pipe and discharge pipe used in the 304 stainless steel grinding disc chamber are made of 304 stainless steel. The belt drive is equipped with the European belt pulley. It is easy to disassemble and repair. According to the requirements of the material grinding number, it is equipped with 10- 120 mesh screen, there is a bouncy ball in the vibrating screen, which is good in material flow and does not block the material.



A2:The grinding disc and the fixed knife gap are adjusted by a specific adjustment (three minutes), which is simple and easy to control the powder size.The main engine is provided with a wind and water circulation cooling system.



A3: The quality SKD11 disc material is easy to replace and can be used repeatedly after grinding.
Milling objects: PE, HDPE, LLDPE, PVC, ABS, EVA, PS, rubber, wood powder and other products.
All are welcome to come to consult, test machine, purchase and incoming powder processing. Customized all kinds of grinding machine grinding discs, moving knives and fixed knives at home and abroad. The new disc design, high output, high wear resistance, life expectancy is twice that of ordinary discs.



zhangjiagang beisu machienry main mahine sales http://www.beisu-extrusion.com: plastic mill, PE mill, PVC mill, grinding disc mill, high-speed mixer, high-speed mixing unit, PVC mixer, high mixer



Details specification pictures of Plastic pulverizer:

1000kg / H High Speed Plastic Pulverizer Machine For PVC / PP / ABS / EVA Material 01000kg / H High Speed Plastic Pulverizer Machine For PVC / PP / ABS / EVA Material 11000kg / H High Speed Plastic Pulverizer Machine For PVC / PP / ABS / EVA Material 2

Technical dates of Plastic pulverizer:

A1:PP/EVA/ABS pulverizer  http://www.beisu-extrusion.com

model MF400 MF500 MF600 MF800
diameter of blade 400MM 500MM 600MM 800MM
main motor power 30kw 45kw 55kw 75kw
blade material SKD-11 or D53 SKD-11 or D53 SKD-11 or D53 SKD-11 or D53
capacity around 100kg/h around 200kg/h around 300kg/h around 500kg/h



A2:HDPE/LLDPE /soft PVC/PET etc pulverizer http://www.beisu-extrusion.com

model MF400 MF500 MF600 MF800
diameter of blade 400MM 500MM 600MM 800MM
main motor power 30kw 45kw 55kw 75kw
blade material SKD-11 or D53 SKD-11 or D53 SKD-11 or D53 SKD-11 or D53
capacity around 100-150kg/h around 250kg/h around 350kg/h around 500kg/h



A3:Hard PVC pulverizer:http://www.beisu-extrusion.com

model MF400 MF500 MF600 MF800
rotary blade qty 18 24 28 40
fixed blade qty 10 12 15 20
main motor power 30kw 45kw 55kw 75kw
blade material high chromium alloy high chromium alloy high chromium alloy high chromium alloy
capacity around 100-150kg/h around 250kg/h around 350kg/h around 500kg/h
