Product Details:
Payment & Shipping Terms:
|
| Output (kg/h): | 500 - 600 Kg/h | Feeding Size (mm): | 8 - 10 Mm |
|---|---|---|---|
| Output Size (mesh): | 20 - 80 Mesh | Power (kW): | 45 |
| Range Of Spindle Speed(r.p.m): | 2900 - 3700 R.p.m | Type: | Pulverizer |
| Voltage: | 220V/380V/415V/440V | Dimension(L*W*H): | 2000mm*2800mm*3200mm |
| Weight (KG): | 2000 KG | Raw Material: | PVC |
| Motor Power: | 90Kw | Material Blade: | High Alloy Steel |
| Blade Type: | Disc | Off Fan Blower Motor Power: | 1.1Kw |
| Fan Blower Motor Power: | 11Kw | Bearing Brand: | NSK |
| OIL Filling System: | Oil Pump | Dust Collection Type: | Bag |
| Contactor Brand: | SIEMENS | Port: | SHANGHAI Or NINGBO PORT |
| High Light: | Disc Blades plastic pulverizer,Rotomoulding plastic pulverizer,Rotomoulding ldpe pulverizer |
||
Plastic LDPE LLDPE rotomoulding pulverizer machine developed by our company under the technical guidance of German experts. It has a wide range of applications in plastics, rubber, chemical and other industries.
A1) The overall structure of the LDPE mill is firm. The overall structure of the machine is compact and firm, which can be used permanently.
A2) LDPE pulverizer has a long service life. The wear resistance is stronger than that of ordinary pulverizers, and the life of the grinding disc is twice that of ordinary grinding discs, which saves costs.
A3) LDPE pulverizer has a wide range of uses. Due to the unique crushing effect of this type of pulverizer, it can grind a variety of plastics. Such as PVC, PE, EVA, ABS, LDPE, HDPE, LLDPE, PP, EPS, PS and other plastics.
A4) The LDPE mill is easy to maintain and clean by opening the door cover, which is simple and convenient.
A5) LDPE powder mill is fully automated operation. Automatic feeding and discharging.
A6) LDPE powder milling confidential closed structure The milling process adopts a fully enclosed, no dust leakage.
Plastic LDPE LLDPE rotomoulding pulverizer machine:
● Plastic pulverizer adopts a new type of cutter structure, which improves the output and overcomes the characteristics of low PE output and coarse powder.
The plastic mill has high output, fine milling, energy saving and environmental protection.
● The plastic mill has a wide range of applications, and can grind PVC, PE, PS, PA, PC and other plastics.
● The plastic mill is easy to install and maintain, and it can be cleaned by opening the door.
● The entire plastic grinding process of the plastic mill is fully sealed, and there is no dust pollution.
● The powder size of the plastic mill is adjustable from 10 to 120 meshes, and it is easy to adjust.
The cooling system of plastic pulverizer adopts wind and water combined cooling.
● High-quality wear-resistant steel knives for plastic pulverizers, with high output and good wear resistance.
● The plastic mill is fully automatic and continuous operation.
● The plastic mill has a compact structure and a small footprint.
● The all-steel structure of the plastic pulverizer is integrated, which is stable and reliable.
● The closed design of the plastic mill uses its own air volume and pressure to collect the prepared powder without any dust leakage.
● Plastic pulverizer This machine can grind all kinds of soft and hard leather into fibrous form at room temperature: artificial leather, PVC, PE and other materials with different molecular structures are ground into 20-80 mesh powder, especially suitable for plastic modification.
Parameters :
| Model | 400 | 500 | 600 | 800 |
| Motor power(kw) | 30 | 37 | 45 | 55 |
| Blower power(kw) | 1.5 | 3 | 5.5 | 11 |
| Dust collector | 6 | 9 | 16 | 24 |
| Total power(kw) | 31.5 | 42 | 52 | 90.5 |
| Feed diameter(mm) | <18 | <18 | <18 | <18 |
| Discharge size(mesh) | 10-80 | 10-80 | 10-80 | 10-80 |
| Capacity(kg/h) | 100-150 | 200-250 | 300-400 | 400-500 |
| Dimension(L*W*H) | 2000*1800*26000 | 2500x2000x3000 | 3200x2600x3200 | 3500x2400x4000 |
