LDPE 45KW PVC Pulverizer Machine Industrial With Wear Resistance

Certification
China Zhangjiagang Beisu Machinery Co., Ltd. certification
China Zhangjiagang Beisu Machinery Co., Ltd. certification
The quality of the machine of Beisu Machinery is very stable, the output is high, the details are very user friendly, and they provide a quick response when we need service.

—— Ahmed Zeitoun

The quality of the high speed mixer produced by Beisu Machinery is outstanding. We have ordered 3 sets of equipment and they are all in use. Maria provides our professional and prompt after sales service.

—— Adrew

I'm Online Chat Now

LDPE 45KW PVC Pulverizer Machine Industrial With Wear Resistance

LDPE 45KW PVC Pulverizer Machine Industrial With Wear Resistance
LDPE 45KW PVC Pulverizer Machine Industrial With Wear Resistance
video play

Large Image :  LDPE 45KW PVC Pulverizer Machine Industrial With Wear Resistance

Product Details:
Place of Origin: CN
Brand Name: BEISU
Certification: ISO
Model Number: MF-800
Payment & Shipping Terms:
Minimum Order Quantity: >=1 Sets
Price: $10,000.00
Packaging Details: Film packing or wood package as customer requirements
Supply Ability: 200 Set/Sets per Year
Detailed Product Description
Output (kg/h): 260-600kg/h Power (kW): 45KW
Range Of Spindle Speed(r.p.m): 2900 - 3700 R.p.m Type: LDPE LLDPE PE HDPE
Voltage: 220V/380V/415V/440V Dimension(L*W*H): 2000mm*2800mm*3200mm
Weight (KG): 2000 KG Raw Material: PVC
Motor Power: 90Kw Blade Type: Disc
Dust Collection Type: Bag Contactor Brand: SIEMENS
High Light:

PVC Pulverizer with wear resistance

,

LDPE 45KW PVC Pulverizer

,

Industrial PVC Pulverizer Machine

MF-600 LDPE LLDPE PE HDPE Pulverizer 45KW Industrial Pulverizer Machine

Technical of LDPE LLDPE PE HDPE Pulverizer 45KW Industrial Pulverizer Machine



Model
MF-400
MF-500
MF-600
MF-800
Disc Dia(mm)
400



500
600
800
Main motor power(KW)
22-30
37-45
45-55
75-90
Fan power(KW)
3
4
5.5
11.5
Vibrosieve Power(KW)
0.75
1.1
1.6
2.2
Capicity(KG/H)
120-200
180-400
260-600
550-950
Machine size(mm)
1700*1500*3400
1800*1600*3600
1900*1700*3800
2300*1900*4200
Machine weight(KG)
1200
1600
2200
3500



LDPE LLDPE PE HDPE Pulverizer 45KW Industrial Pulverizer Machine



● Plastic pulverizer adopts a new type of cutter structure, which improves the output and overcomes the characteristics of low PE output and coarse powder.
The plastic mill has high output, fine milling, energy saving and environmental protection.
● The plastic mill has a wide range of applications, and can grind PVC, PE, PS, PA, PC and other plastics.
● The plastic mill is easy to install and maintain, and it can be cleaned by opening the door.
● The entire plastic grinding process of the plastic mill is fully sealed, and there is no dust pollution.
● The powder size of the plastic mill is adjustable from 10 to 120 meshes, and it is easy to adjust.
The cooling system of plastic pulverizer adopts wind and water combined cooling.
● High-quality wear-resistant steel knives for plastic pulverizers, with high output and good wear resistance.
● The plastic mill is fully automatic and continuous operation.
● The plastic mill has a compact structure and a small footprint.
● The all-steel structure of the plastic pulverizer is integrated, which is stable and reliable.
● The closed design of the plastic mill uses its own air volume and pressure to collect the prepared powder without any dust leakage.
● Plastic pulverizer This machine can grind all kinds of soft and hard leather into fibrous form at room temperature: artificial leather, PVC, PE and other materials with different molecular structures are ground into 20-80 mesh powder, especially suitable for plastic modification.



Parameters of LDPE LLDPE PE HDPE Pulverizer 45KW Industrial Pulverizer Machine



● Plastic pulverizer adopts a new type of cutter structure, which improves the output and overcomes the characteristics of low PE output and coarse powder.
The plastic mill has high output, fine milling, energy saving and environmental protection.
● The plastic mill has a wide range of applications, and can grind PVC, PE, PS, PA, PC and other plastics.
● The plastic mill is easy to install and maintain, and it can be cleaned by opening the door.
● The entire plastic grinding process of the plastic mill is fully sealed, and there is no dust pollution.
● The powder size of the plastic mill is adjustable from 10 to 120 meshes, and it is easy to adjust.
The cooling system of plastic pulverizer adopts wind and water combined cooling.
● High-quality wear-resistant steel knives for plastic pulverizers, with high output and good wear resistance.
● The plastic mill is fully automatic and continuous operation.
● The plastic mill has a compact structure and a small footprint.
● The all-steel structure of the plastic pulverizer is integrated, which is stable and reliable.
● The closed design of the plastic mill uses its own air volume and pressure to collect the prepared powder without any dust leakage.
● Plastic pulverizer This machine can grind all kinds of soft and hard leather into fibrous form at room temperature: artificial leather, PVC, PE and other materials with different molecular structures are ground into 20-80 mesh powder, especially suitable for plastic modification.
