100~1000Kg/h Plastic PE PVC SPC WPC Pipe / Profile / Sheets Crushing Machine

Certification
China Zhangjiagang Beisu Machinery Co., Ltd. certification
China Zhangjiagang Beisu Machinery Co., Ltd. certification
The quality of the machine of Beisu Machinery is very stable, the output is high, the details are very user friendly, and they provide a quick response when we need service.

—— Ahmed Zeitoun

The quality of the high speed mixer produced by Beisu Machinery is outstanding. We have ordered 3 sets of equipment and they are all in use. Maria provides our professional and prompt after sales service.

—— Adrew

I'm Online Chat Now

100~1000Kg/h Plastic PE PVC SPC WPC Pipe / Profile / Sheets Crushing Machine

100~1000Kg/h Plastic PE PVC SPC WPC Pipe / Profile / Sheets Crushing Machine
100~1000Kg/h Plastic PE PVC SPC WPC Pipe / Profile / Sheets Crushing Machine 100~1000Kg/h Plastic PE PVC SPC WPC Pipe / Profile / Sheets Crushing Machine 100~1000Kg/h Plastic PE PVC SPC WPC Pipe / Profile / Sheets Crushing Machine 100~1000Kg/h Plastic PE PVC SPC WPC Pipe / Profile / Sheets Crushing Machine 100~1000Kg/h Plastic PE PVC SPC WPC Pipe / Profile / Sheets Crushing Machine

Large Image :  100~1000Kg/h Plastic PE PVC SPC WPC Pipe / Profile / Sheets Crushing Machine

Product Details:
Place of Origin: CHINA
Brand Name: BEISU
Certification: CE
Model Number: BS-800
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: $8000
Packaging Details: Wooden case package or film package
Delivery Time: 35 working days
Payment Terms: L/C, T/T, Western Union
Supply Ability: 100 sets per year
Detailed Product Description
Name: Crusher For Plastic Recycling Suitable Material: PVC/WPC/PP/PE/PPR/PC/ABS/PMMA/PS
Blade Material: D2 Motor Power: 45 Or 55Kw
Knife Roll: Solid Knife Roller Knife Classification: Claw Knife Crusher
Bearing Brand: NSK Or SKF System: Frequency-Controlled Hydraulic System
Highlight:

1000Kg/h plastic sheet crushing machine

,

100Kg/h plastic sheet crushing machine

,

WPC plastic sheet crushing machine

Product Application for Plastic PVC crushing machine:
100~1000Kg/h Plastic PE PVC SPC WPC Pipe / Profile / Sheets Crushing Machine 0



SWP series Plastic crusher is mainly used for crushing all kinds of plastic profile and pipe materials. It does not need to cut and segment the long plastic pipe, and can continuously feed material at one time. Such as plastic doors, plastic tubes, plastic plates, window frames, trunking, sheets and so on.

The crusher can realize automatic feeding, and the entire pipe is put into the machine to crush on its own; a fan is used to transport the broken material device, and the broken qualified particles are pulled out from the machine by the suction fan to facilitate bagging and warehousing; The device, and the large SWP model is equipped with an independent control box. The operation and maintenance are extremely convenient and it is the ideal model for crushing various pipes and profiles.
100~1000Kg/h Plastic PE PVC SPC WPC Pipe / Profile / Sheets Crushing Machine 1

Crusher wearing parts for the blade, long-term use will wear out. We usually use yttrium-chromium-silicon (9GrSi) high-quality alloy steel blades, which have stronger wear resistance and impact resistance than ordinary materials, and can be repeatedly used after being used for a long time after blunt knife-edge, which greatly reduces the cost. According to the different requirements of customers, it can also be equipped with imported tools to better improve the performance of the machine.
100~1000Kg/h Plastic PE PVC SPC WPC Pipe / Profile / Sheets Crushing Machine 2



SWP-400 powerful crusher can crush PVC pipe and corrugated pipe with diameter less than 160mm, PE pipe with diameter less than 100, wire trough, sheet, decoration board. Larger diameter plastic pipes are easily broken after cutting.

SWP-500 powerful crusher and heavy crusher can crush PVC pipes below 250mm in diameter, PE pipes under 160mm in diameter, PP pipes under 110 diameter, PPR pipes and other plastic pipes and profiles.

SWP-600 powerful crusher and heavy crusher can crush plastic pipes below 315mm in diameter. It can also be broken after larger diameter and thicker pipes are cut in sections. For thicker plates, bars, car bumpers, Large injection molded parts can also be broken. For larger and larger calibers (such as below 800mm and below 1200mm), there are crushing solutions.



Technical Parameter of SWP Plastic crushing machine:

Model SWP 400 SWP 500 SWP 560 SWP 650
Rotary knife 5 pcs 5 pcs 10 pcs 10 pcs
static knife 2 pcs 2 pcs 4 pcs 4 pcs
Blade
specification
315*100*22mm 415*100*22mm 250*100*22mm 300*100*25mm
Motor power 15 KW 18.5 KW 22-30 KW 37 KW
Output 200-300 Kg/h 300-350kg/h 350-500kg/h 450-650kg/h
Dimensions 1850*900*1630mm 1850*1050*1680mm 2050*1150*1730mm 2400*1350*1850mm
Weight 1200kg 1300kg 1600kg 2100kg



100~1000Kg/h Plastic PE PVC SPC WPC Pipe / Profile / Sheets Crushing Machine 3

100~1000Kg/h Plastic PE PVC SPC WPC Pipe / Profile / Sheets Crushing Machine 4

100~1000Kg/h Plastic PE PVC SPC WPC Pipe / Profile / Sheets Crushing Machine 5

100~1000Kg/h Plastic PE PVC SPC WPC Pipe / Profile / Sheets Crushing Machine 6

100~1000Kg/h Plastic PE PVC SPC WPC Pipe / Profile / Sheets Crushing Machine 7

100~1000Kg/h Plastic PE PVC SPC WPC Pipe / Profile / Sheets Crushing Machine 8

100~1000Kg/h Plastic PE PVC SPC WPC Pipe / Profile / Sheets Crushing Machine 9

100~1000Kg/h Plastic PE PVC SPC WPC Pipe / Profile / Sheets Crushing Machine 10

100~1000Kg/h Plastic PE PVC SPC WPC Pipe / Profile / Sheets Crushing Machine 11

100~1000Kg/h Plastic PE PVC SPC WPC Pipe / Profile / Sheets Crushing Machine 12

100~1000Kg/h Plastic PE PVC SPC WPC Pipe / Profile / Sheets Crushing Machine 13

100~1000Kg/h Plastic PE PVC SPC WPC Pipe / Profile / Sheets Crushing Machine 14

100~1000Kg/h Plastic PE PVC SPC WPC Pipe / Profile / Sheets Crushing Machine 15

100~1000Kg/h Plastic PE PVC SPC WPC Pipe / Profile / Sheets Crushing Machine 16



100~1000Kg/h Plastic PE PVC SPC WPC Pipe / Profile / Sheets Crushing Machine 17

Zhangjiagang Beisu Machinery Co,Ltd is a certified manufacturer, exporter and supplier of
plastic PVC/PE/PP/PET/EVA/ABS processing machinery. Due to our constant commitment to
extrusion technology, we have emerged as a leading manufacturer of Plastic Extrusion
Machinery for PVC pipes Extrusion Line, HDPE pipes Extrusion Line, PVC compounding
Extruder, PPR Pipes Extrusion Line, PVC profiles Extrusion Line.
Especially High speed Plastic mixer, PVC compounding mixer, SPC mixer.WPC mixer,Plastic Granulating and Pelletizing Line,Plastic pvc pelletizing machine,Soft PVC shoes granulator, PVC compounding pelletizer and Plastic PVC pulverizer, PVC miller,SPC milling machine, WPC pulverizer, SPC pulverizer, PE pulverizer,LDPE pulverizer,PET pulverizer,ABS pulverizer,HDPE pulverizer,Plastic pulverizer, Plastic milling machine, Plastic miller machine,Plastic Crusher,PVC crusher,PE crusher,PP shredder, Plastic PVC Shredder etc for a wide range of extrusion processes.
Installation Instructions

1. Before shipment testing at factory, vedio record.
2. Vedio instruction for operation.
3. User manual and installation instruction, layout and drawings.
4. Lable&marks for disassemble parts, wiring&cables.

Our Advantages

1.Reliable

  • Most popular design with years' verification.

  • Mature supply chain for raw materials with strict quality assurance.

  • International famous brands of key parts i.e. ABB invertor, Siemens electronics, Siemens motor, Mettler Toledo scale etc.

2. Economy

  • BEISU Stable technology commercialized in China.

  • High efficiency mixing performance.

  • Cost effective solutions.

After Sales Service

Real time communication SNS group chat(WeChat preferred, Skype/WhatsApp) which includes buyer side and BEISU service team is created for technical assistance in the quickest manner. Scheduled video calls are also available. Just as the company vision 'Customer Oriented' says,BEISU always stands at customer's point to offer the optimum solution and help customer to maximize profit. BEISU has its own customer management system and spare parts management system which ensure quickest responds and enough regular easy-wearing parts whenever customer requests.
